MXL Timing Belt

Precision Small-Pitch Synchronous Belt

MXL Timing Belt is asmall-pitch synchronous beltdesigned for precision power transmission in compact and light-duty applications.

With a pitch of0.08 inch (2.032 mm), MXL belts deliver accurate positioning, smooth engagement, and stable operation, making them ideal for precision equipment requiring reliable synchronization.

Sables MXL timing belts are manufactured with optimized rubber compounds and reinforced tensile cords to ensure long service life and consistent performance.

MXL Timing Belt Specifications

Below is the available specification range of Sables MXL timing belts, including belt width, tooth count, and length options.If you cannot find the exact size you need, custom MXL timing belts are available.Tip: Use Ctrl + F (Windows) or Command + F (Mac) to quickly search for the MXL timing belt size, tooth number, or length you need in the table below.

Contact Us

TYPE	Length (mm)	Tooth Number	more
B40	81.28	40	View Contact
B45	91.44	45	View Contact
B46	93.472	46	View Contact
B47	95.504	47	View Contact
B48	97.536	48	View Contact
B49	99.568	49	View Contact
B50	101.6	50	View Contact
B51	103.632	51	View Contact
B52	105.664	52	View Contact
B53	107.696	53	View Contact
B54	109.728	54	View Contact
B55	111.76	55	View Contact
B56	113.792	56	View Contact
B57	115.824	57	View Contact
B58	117.856	58	View Contact
B59	119.888	59	View Contact
B60	121.92	60	View Contact
B61	123.952	61	View Contact
B62	125.984	62	View Contact
B63	128.016	63	View Contact
B64	130.048	64	View Contact
B65	132.08	65	View Contact
B66	134.112	66	View Contact
B67	136.144	67	View Contact
B68	138.176	68	View Contact
B69	140.208	69	View Contact
B70	142.24	70	View Contact
B71	144.272	71	View Contact
B72	146.304	72	View Contact
B73	148.336	73	View Contact
B74	150.368	74	View Contact
B75	152.4	75	View Contact
B76	154.432	76	View Contact
B77	156.464	77	View Contact
B78	158.496	78	View Contact
B79	160.528	79	View Contact
B80	162.56	80	View Contact
B81	164.592	81	View Contact
B82	166.624	82	View Contact
B83	168.656	83	View Contact
B84	170.688	84	View Contact
B85	172.72	85	View Contact
B86	174.752	86	View Contact
B87	176.784	87	View Contact
B88	178.816	88	View Contact
B89	180.848	89	View Contact
B90	182.88	90	View Contact
B91	184.912	91	View Contact
B92	186.944	92	View Contact
B93	188.976	93	View Contact
B94	191.008	94	View Contact
B95	193.04	95	View Contact
B96	195.072	96	View Contact
B97	197.104	97	View Contact
B98	199.136	98	View Contact
B99	201.168	99	View Contact
B100	203.2	100	View Contact
B101	205.232	101	View Contact
B102	207.264	102	View Contact
B103	209.296	103	View Contact
B104	211.328	104	View Contact
B105	213.36	105	View Contact
B106	215.392	106	View Contact
B107	217.424	107	View Contact
B108	219.456	108	View Contact
B109	221.488	109	View Contact
B110	223.52	110	View Contact
B111	225.552	111	View Contact
B112	227.584	112	View Contact
B113	229.616	113	View Contact
B114	231.648	114	View Contact
B115	233.68	115	View Contact
B116	235.712	116	View Contact
B118	239.776	118	View Contact
B119	241.808	119	View Contact
B120	243.84	120	View Contact
B121	245.872	121	View Contact
B122	247.904	122	View Contact
B123	249.936	123	View Contact
B124	251.968	124	View Contact
B125	254	125	View Contact
B126	256.032	126	View Contact
B127	258.064	127	View Contact
B128	260.096	128	View Contact
B130	264.16	130	View Contact
B131	266.192	131	View Contact
B132	268.224	132	View Contact
B133	270.256	133	View Contact
B134	272.288	134	View Contact
B135	274.32	135	View Contact
B136	276.352	136	View Contact
B137	278.384	137	View Contact
B138	280.416	138	View Contact
B139	282.448	139	View Contact
B140	284.48	140	View Contact
B142	288.544	142	View Contact
B143	290.576	143	View Contact
B144	292.608	144	View Contact
B145	294.64	145	View Contact
B146	296.672	146	View Contact
B147	298.704	147	View Contact
B148	300.736	148	View Contact
B149	302.768	149	View Contact
B150	304.8	150	View Contact
B151	306.832	151	View Contact
B152	308.864	152	View Contact
B153	310.896	153	View Contact
B154	312.928	154	View Contact
B155	314.96	155	View Contact
B156	316.992	156	View Contact
B157	319.024	157	View Contact
B158	321.056	158	View Contact
B159	323.088	159	View Contact
B160	325.12	160	View Contact
B161	327.152	161	View Contact
B162	329.184	162	View Contact
B165	335.28	165	View Contact
B166	337.312	166	View Contact
B169	343.408	169	View Contact
B170	345.44	170	View Contact
B171	347.472	171	View Contact
B175	355.6	175	View Contact
B177	359.664	177	View Contact
B180	365.76	180	View Contact
B184	373.888	184	View Contact
B185	375.92	185	View Contact
B186	377.952	186	View Contact
B188	382.016	188	View Contact
B189	384.048	189	View Contact
B190	386.08	190	View Contact
B192	390.144	192	View Contact
B194	394.208	194	View Contact
B195	396.24	195	View Contact
B197	400.304	197	View Contact
B200	406.4	200	View Contact
B203	412.496	203	View Contact
B205	416.56	205	View Contact
B210	426.72	210	View Contact
B212	430.784	212	View Contact
B215	436.88	215	View Contact
B216	438.912	216	View Contact
B218	442.976	218	View Contact
B219	445.008	219	View Contact
B221	449.072	221	View Contact
B224	455.168	224	View Contact
B225	457.2	225	View Contact
B228	463.296	228	View Contact
B229	465.328	229	View Contact
B232	471.424	232	View Contact
B235	477.52	235	View Contact
B236	479.552	236	View Contact
B239	485.648	239	View Contact
B240	487.68	240	View Contact
B245	497.84	245	View Contact
B250	508	250	View Contact
B256	520.192	256	View Contact
B260	528.32	260	View Contact
B265	538.48	265	View Contact
B270	548.64	270	View Contact
B275	558.8	275	View Contact
B276	560.832	276	View Contact
B280	568.96	280	View Contact
B284	577.088	284	View Contact
B285	579.12	285	View Contact
B290	589.28	290	View Contact
B292	593.344	292	View Contact
B297	603.504	297	View Contact
B300	609.6	300	View Contact
B310	629.92	310	View Contact
B312	633.984	312	View Contact
B318	646.176	318	View Contact
B320	650.24	320	View Contact
B322	654.304	322	View Contact
B328	666.496	328	View Contact
B332	674.624	332	View Contact
B346	703.072	346	View Contact
B347	705.104	347	View Contact
B350	711.2	350	View Contact
B358	727.456	358	View Contact
B363	737.616	363	View Contact
B372	755.904	372	View Contact
B378	768.096	378	View Contact
B380	772.16	380	View Contact
B400	812.8	400	View Contact
B405	822.96	405	View Contact
B435	883.92	435	View Contact
B438	890.016	438	View Contact
B453	920.496	453	View Contact
B482	979.424	482	View Contact
B487	989.584	487	View Contact
B500	1016	500	View Contact
B510	1036.32	510	View Contact
B516	1048.512	516	View Contact
B522	1060.704	522	View Contact
B525	1066.8	525	View Contact
B532	1081.024	532	View Contact
B648	1316.736	648	View Contact
B705	1432.56	705	View Contact
B760	1544.32	760	View Contact
B906	1840.992	906	View Contact

Applications of MXL Timing Belts

MXL timing belts are commonly used in precision equipment where accurate motion control and compact structure are required.Sables MXL timing belts are designed to maintain stable performance even during long-term continuous operation.

Textile Industry

Packaging Machines

Printers & Office Equipment

Automation Equipment

Medical Devices

Electronics & Semiconductor Equipmen

Small Conveyors & Positioning Systems

Why Choose Sables MXL Timing Belts

Sables focuses on real industrial applications, providing MXL timing belts that meet practical operating requirements rather than theoretical specifications.

High Synchronization Accuracy

Precise tooth profile ensures accurate synchronization and stable engagement.

Low Noise & Smooth Operation

Optimized rubber formulation reduces vibration and operating noise.

Durable & Wear-Resistant

Excellent resistance to wear, oil, and temperature variations.

Stable Quality Control

Strict manufacturing and inspection standards ensure consistency across batches.

Custom Support Available

Support for special length, width, or application-specific requirements.

FAQs About MXL Timing Belt

Can Sables help optimize existing transmission systems?
Transmission optimization scheme
How does Sables support OEM machine manufacturers?
Sables support OEM machine manufacturers
What are common belt problems in textile machines?
Common belt problems in textile machines

Contact Sables for MXL Timing Belt Solutions

If you need technical support, specification confirmation, or custom MXL timing belt solutions, feel free to contact Sables.
